Changes Included in the Stable release 23.08 of Azul Zulu Prime Builds of OpenJDK

The latest Long Term Support (LTS) version of OpenJDK was released on September 19, 2023. Below is an overview of all the combined improvements in the latest Azul Prime Builds of OpenJDK, stable release, 23.08.01.0.

Azul Platform Prime is a modern, TCK-compliant Java platform based on OpenJDK. It provides consistently low response latency of your Java workloads, higher total throughput and carrying capacity, faster warmup, and infrastructure savings, achieved thanks to the C4 pauseless garbage collector, Falcon JIT compiler, and other technologies created by Azul. Prime Builds are available in two versions, either for evaluation or production use:

• Stream Builds: Fast-moving monthly releases (end of the month) that include the latest features and changes in PSU releases. These are free for development and evaluation. The use in production requires an active subscription. Their version number is based on year and month. For instance, “23.07.0.0” is the July Stream Build of 2023.
• Stable Builds: Builds that incorporate only critical patch updates (CPUs), patch set updates (PSUs), and Azul Platform Prime critical fixes. Stable builds do not include new features or non-critical enhancements from stream builds. Stable builds are our primary vehicle for delivering time-sensitive bug fixes to customers and are only available to Azul customers. Their version number is based on the stream build they originated from. For instance, “22.02.501.0” is derived from the February stream build of 2022; but it already had multiple updates, as the 501 number indicates.

As stream builds happen in a fixed schedule, all changes are included in the release notes. Twice a year (in February and August), a stream build becomes the new stable build, providing a new version with many more improvements. In this post, we want to give you an overview of all the combined improvements in the latest stable release, 23.08.01.0.

Changes Included in 23.08.1.0

As stable builds overlap, your system should be on the 23.02-stable line, and there are now four months of overlap with the 23.08-stable builds. Let’s look at some of the most significant changes between 23.02 and 23.08 and the changes included in the new Stable Build 23.08.01.00 released on September 26, 2023.

Security fixes

April and July 2023 CPU and PSU release security fixes.

Changes in supported versions

JDK versions 13, 15, and 19 are no longer included in Prime stable releases. Only the JDK Long Term Support (LTS) versions 8, 11, and 17 continue to be included.

New Supported Platforms

Oracle Linux (Centos 7.9) ARM is now supported since Azul Platform Prime 23.03.0.0.

Optimizer Hub

The client for Optimizer Hub has been upgraded to support the latest features of Optimizer Hub version 1.8. This upgrade aligns the client in Prime to support the components provided in Optimizer Hub (formerly Cloud Native Compiler). As Cloud Native Compiler expands its scope to offer more functionality than just offloading compilations, it is time to rebrand the offering to reflect better what it does. Starting with release 1.8, we are using the following names:

• Optimizer Hub (formerly Cloud Native Compiler): The name of the overall component you install on your Kubernetes cluster.
  • Cloud Native Compiler (formerly Compiler Service): Server-side optimization solution that offloads JIT compilation to separate, dedicated service resources. Cloud Native Compiler provides more processing power to JIT compilation while freeing your client JVMs from the burden of doing JIT compilation locally.
  • ReadyNow Orchestrator (formerly Profile Log Service): Records and serves ReadyNow profiles. This greatly simplifies the operational use of ReadyNow and removes the need to configure any local storage for writing the profile. ReadyNow Orchestrator can record multiple profile candidates from multiple JVMs and promote the best-recorded profile.

In Optimizer Hub 1.8, all major artifacts and command line switches use the updated branding. This includes, but is not limited to:

• Command-line JVM options to configure Cloud Native Compiler and ReadyNow Orchestrator. See Command Line Options.
• Helm repository locations, names, and parameter names: github.com/AzulSystems/opthub-helm-charts.
• REST API URLs.

All documentation of Optimizer Hub can be found on docs.azul.com/optimizer-hub.

Native Memory Tracking (NMT)

It is no longer necessary to LD_PRELOAD the libnmt_hooks.so library to use extended Native Memory Tracking (NMT). The libnmt_hooks.so library is now linked by default.

Falcon Compiler

Azul Platform Prime 23.05.0.0 brought several performance optimizations, including many intrinsic functions implemented in the Falcon compiler.

Compilation ranks by priority, which allows the JVM to assign compilation ranks to methods, has been introduced to Azul Platform Prime 23.08.0.0. This allows the Falcon compiler to assign ranks (hot, warm, or cold) to methods to prioritize system resources to methods depending on their hotness. For more information on compilation ranks, see Analyzing and Tuning Warmup. For newly added options, see Command Line Options.

Java Flight Recorder

Using Java Flight Recorder, you can now see exact JIT names for each stacktrace frame in Azul Mission Control in the Method Profiling tab. This uses the option JFRDistinguishJITTypes, which is set to true by default, and shows either C1, C2, or Falcon for each stacktrace frame. With JFRDistinguishJITTypes set to false, it shows JIT compiled.

Per Thread CPU Utilization in GC Log

The per-thread CPU (Central Processing Unit) utilization tracking feature, available from Azul Platform Prime 23.06, allows the collection and charting of per-thread CPU core usage statistics. This lets you view the CPU usage of an application and the JVM internal threads of the process over time. JVM internal threads are grouped into known categories (for example, compiler or GC group) to make analysis of threads simpler. There is also an option to include CPU usage from other processes on the system.

Per-thread CPU utilization is turned on using the option `-XX:+PrintCPUUtilization`, which is disabled by default due to the potential overhead from data collection.

Changes in Command Line Options

• The Command Line Option GPGCUseAllocationPacing has been disabled by default.
• The Command Line Option CNCForceLocalCompiler has been deprecated and replaced with the new option CNCEnableRemoteCompiler.
• The command line option, AllocCodeCacheInLower2G, is now supported on the aarch64 system architecture, which is set to true by default. This option allocates code cache and related data structures at virtual address within 2 GB. To allow allocation to higher memory addresses, use -XX:-AllocCodeCacheinLower2G.
• A new command line option, GPGCCommitInitialHeapLazily, has been introduced, which is set to false by default. When enabled, this option prevents the whole of the initial heap size, InitialHeapSize or -Xms, from being committed from the OS upfront.With this option enabled, use the option GPGCLazyInitialHeapCommitPercent to specify how much of Xms shall be committed from the OS upfront, at startup. The default value for GPGCLazyInitialHeapCommitPercent is 50. The remainder gets committed based on regular elastic heap heuristics.
• The command line option InitialHeapSize is now incorporated in Azul Platform Prime in order to keep compatibility with OpenJDK. InitialHeapSize can be used instead of -Xms<size> on the command line.
  TIP: The command line argument MaxHeapSize can also be used instead of -Xmx<size>.
• The command line option PreferContainerQuotaForVMInternalCPUCount has been set to true by default to make calculations of internal thread counts, as well as budgeting options, more clear in container environments. In container environments where both CPU shares and CPU quota are specified, such as with Kubernetes where these are commonly specified, the VM now uses quota to calculate compiler and GC thread counts. Prior to Azul Platform Prime 23.08, it was using half of the quota for the calculation.
• Some Falcon CPU Budgeting options have been renamed according to the following table:

For more information on Falcon CPU Budgeting options, see Command Line Options, CPU Budgeting Options

The command line option UseTrueObjectsForUnsafe has been set to true by default. This option forces unsafe objects to be returned in their true object form instead of the equivalent java class object. For example, with UseTrueObjectsForUnsafe disabled, java.lang.Class can be returned instead of the true klassOop.

A new option, C2CompileThreshold, has been added. This option allows the C2 compile threshold to be specified for individual methods. This option was introduced because some methods that are rarely called are still important and need to undergo regular optimization. This is set using -XX:CompileCommand in the following way:

-XX:CompileCommand="option,<Class>::<method>,C2CompileThreshold=<threshold>"

The command line option -XX:CompileCommand has been updated to use FalconCompileThreshold.

This option is used in the following way:

-XX:CompileCommand="option,<Class>::<method>,FalconCompileThreshold=<threshold value>"

The maximum supported code cache size has been increased to 1758 MB when AllocCodeCacheInLower2G is disabled using -XX:-AllocCodeCacheInLower2G.

Due to rebranding of Cloud Native Compiler to Optimizer Hub, some options have been renamed according to the following table:

Deprecation of ZVTools

ZVision and ZVRobot components have been deprecated and are no longer actively developed. While we still support these components, we encourage users to switch to Java Flight Recorder, as ZVision and ZVRobot are planned for End-of-life with Azul Platform Prime 24.02.0.0.

Resolved Issues

Conclusion

The new Stable Azul Zulu Prime Build of OpenJDK brings many improvements and fixes to bring a more performant and secure runtime to your environment.
